M.2 PCIe SSD

AS2280P4U Pro M.2 PCIe Gen3 x4

M.2 PCIe SSD

AS2280P4U Pro M.2 PCIe Gen3 x4

  • The latest generation PCIe Gen 3x4 speed
  • Complies with the latest NVMe 1.3 specification
  • Extremely thin and light M.2 interface
  • Continuous read speed up to 3,500MB/s; continuous write speed up to 3,000MB/s
  • Aluminum heat sink effectively reduce temperatures by up to 25%
  • 5-year Warranty Gives Peace of Mind

Multi-task in the Blink of an Eye

The AS2280P4U Pro adopts PCIe Gen3 x4 interface, conformed to NVMe 1.3 standard. Its excellent read-write speeds are up to 3,500/3,000 MB/s, allowing users to quickly switch from one program to another, never holding them back in their quest for gaming excellence.

Game, Install, Shoot and Edit at a Pro Level

The compact M.2 2280 (22mm x 80mm) frame of AS2280P4U Pro can accommodate a large storage space of up to 2TB. And an ultra-thin design enhances the SSD’s flexibility, making it ideal for ultra-thin laptops, gaming consoles and mini PC builds. Its extraordinary performance will make it a preferred SSD for professionals such as custom installers, e-sports players, overclockers, and videographers.

Keep Things Cool with an Aluminum Heat Sink

The AS2280P4U Pro is equipped with an integrated heat sink made from a single sheet of aluminum, which uses the advantages of high thermal conductivity and high temperature resistance to reduce temperatures by up to 25%. This helps reduce wear and tear on the SSD while also maintaining rock-solid performance.

Data Protection Technology Delivers Consistent Performance

To provide users with a flawless high-speed experience, the AS2280P4U Pro have a number of built-in protection technologies to effectively ensure the accuracy and stability of data transmission. SLC Caching uses an advanced layered cache structure to improve the speed performance of the product. With the built-in advanced wear leveling technology and automatic error correction functions, it can not only extend the service life of the SSD and improve operational stability, but also ensure that the product maintains consistent performance after long-term use.

Spec
  • Product Name
    AS2280P4U Pro
  • Capacity
    256GB~2TB
  • Interface
    PCIe Gen3 x4
  • NAND Flash
    3D NAND
  • Sequential Read Performance
    Up to 3,500 MB/s
  • Sequential Write Performance
    Up to 3,000 MB/s

    *The performance may vary due to host hardware, software , usage and storage capacity.
  • IOPs (4K Random Write)
    Up to 360,000 IOPS
  • Shock
    1,500G/0.5msec
  • MTBF
    1,800,000 hours
  • Standard Operating Temperature
    0°C ~ +70°C
  • Storage Temperature
    -40 ~ +85°C
  • Dimensions
    Single side : (L)80.00 x (W)22.00 x (H)3.75mm
    Double side : (L)80.00 x (W)22.00 x (H)5.0mm
    Weight: 10.3g
  • Certificate
    CE, FCC, VCCI, BSMI, RoHS
  • Warranty
    5-Year Limited Warranty
    *The SSD is based on the TBW or warranty period.
