Industrial USB Module: UH110-UFM3 with Housing

Apacer’s UH110-UFM3 is a high performance, embedded solid state drive (SSD) designed to replace a conventional IDE hard disk drive. As an embedded flash storage, UH110-UFM3 is compliant with USB 2.0 and backward compliable with USB 1.1.
Utilizing 3D NAND for capacity up to 64GB and providing more power efficiency than 2D NAND, UH110-UFM3 can be plugged into a standard Embedded USB connector commonly found in desktops, portable PC systems and industrial PC systems.

Regarding reliability, UH110-UFM3 is not only implemented with LDPC (Low Density Parity Check) ECC engine to extend SSD endurance and increase data reliability, but also equipped with SLC-liteX technology to offer higher number of P/E cycles up to 30,000 times.

In terms of flash management, UH110-UFM3 adopts the latest Page Mapping file translation layer and comes with various implementations including power saving modes, Wear Leveling, flash block management, power failure management, S.M.A.R.T. and Smart Read Refresh™.

UH110-UFM3 is well suited for embedded flash storage applications offering new and expanded functionality as well as more cost-effective designs, better performance and increased reliability.

Spec

Model

UH110-UFM3 with Housing
Interface

USB 2.0
Connector

10-pin USB (2 x 5 header)
Form Factor

USB Disk Module
NAND Flash Type

3D TLC
Capacity

32GB~64GB
External DRAM

No
Sequential Read Performance (MB/sec)

Up to 37
Sequential Write Performance (MB/sec)

Up to 32
ECC Engine

Low-Density Parity-Check (LDPC) Code
IOPS (4K Random Write)

400
Standard Operating Temperature (°C )

0 ~ + 70
Extended Operating Temperature(°C )

-40 ~ + 85
Storage Temperature(°C )

-55 ~ + 100
Housing

Yes
H/W Write Protect

Optional
Screw Hole

No
Shock

Operating: Acceleration, 50(G)/11(ms)/half sine
(compliant with MIL-STD-202G)
Non-operating: Acceleration, 1500(G)/0.5(ms)/half sine
(compliant with MIL-STD-883K)
Vibration

Operation: 7.69 Grms, 20~2000 Hz/random
(compliant with MIL-STD-810G)
Non-operation: 4.02 Grms, 15~2000 Hz/random
(compliant with MIL-STD-810G)
Operating Voltage

5.0 V ± 5%
Power Consumption

Active mode: 95 mA; Idle mode: 75 mA
Dimension (L x W x H )

35.70 x 28.10 x 7.20 mm
MTBF (hours)

>3,000,000
