DDR5 RDIMM
DDR5 RDIMM
- The first fully lead-free memory module that avoids relying on RoHS 7(c)-I lead exemption clause
- High-quality new-generation DDR5 DRAM chips from original DRAM manufacturers
- VDD = VDDQ = 1.1V
- VPP = 1.8V
- 32 internal banks structure, 8 bank groups x 4 banks
- PCB: gold finger design with gold plating thickness up to 30μ
- Halogen free
- Conformal Coating / Underfill (optional)
- Anti-sulfuration (Apacer patented) (optional)
Fully Lead-free DDR5 RDIMM Industrial-grade Memory
Apacer's fully lead-free DDR5 RDIMM industrial-grade memory uses high-quality original chips, which not only exceed the requirements of the current EU RoHS environmental protection standards, but also avoid relying on the lead exemption clause of RoHS 7(c)-I. In addition to the characteristics of ultra-high performance, capacity upgrade, and extremely low power consumption,
Apacer DDR5 RDIMM industrial-grade memory is equipped with a 12V power management IC and a high-precision temperature sensor, which can efficiently control the system power load, strengthen signal integrity and reduce interference. At the same time, they can monitor the memory temperature in real time, to prevent the risk of overheating and maintain high memory performance. It supports the dual error correction mechanism of On-die ECC and Side-band ECC, and also provides end-to-end complete protection for the data transmission process, satisfying the reliability, availability and maintainability requirements of the 24/7 operation of the data center.
The RDIMM (ECC Registered DIMM) module conforms to the JEDEC standard design and is suitable for enterprise servers and cloud data centers. The RDIMM design adds a register between the memory module and the system memory controller, which can improve overall system stability and increase the number of memory modules, while also supporting ECC, which can detect and correct data errors. The built-in thermal sensor monitors memory temperature, prevents memory modules from overheating, and enhances the reliability of the module.
-
ModelDDR5 RDIMM
-
Module TypeFully lead-free RDIMM
-
Memory TechnologyDDR5
-
Speed4800/5600
-
Density16GB/32GB/64GB/128GB
-
Voltage1.1v
-
Pin Count288-Pin
-
Width80-Bit
-
PCB Height1.23"
-
Operating Temperature (°C)TC=0℃ to 85℃
-
Fully Lead-Free ResistorYes
-
Value-added TechnologyThermal Sensor / 30μ Gold Finger
-
Recommended ApplicationHealthcare / Server & Networking
