M.2

SV24C-M280 CoreSnapshot 3 Cloud Edition

M.2

SV24C-M280 CoreSnapshot 3 Cloud Edition

  • Low-Density Parity-Check (LDPC) Code
  • Global Wear-leveling
  • Flash Bad-block Management
  • S.M.A.R.T.
  • End-to-End Data Protection
  • Sidefill Technology
  • CoreSnapshot 3
  • ATA Secure Erase
  • TRIM
  • Flash Translation Layer: Page Mapping
  • Hyper Cache Technology
  • Over-provisioning
  • Device Sleep
  • SATA Power Management
  • DataRAID
  • SMART Read Refresh
  • DataDefender

SV24C-M280 Ensures Outstanding Performance and Security
with Advanced Instant Recovery and Security Technologies



Apacer SV24C-M280 with CoreSnapshot 3 technology is designed with a SATA 6 Gb/s interface, fully complying with the latest SATA Revision 3.2 interface specifications, delivering exceptional read and write speeds. These features make it the perfect choice for demanding industrial or server operations with heavy workloads.



With Apacer’s storage solutions, you’ll experience:

  • 3D NAND Technology: Offer superior power efficiency than 2D NAND.
  • Instant Recovery: CoreSnapshot Technology minimizes downtime and maximums output.
  • Ensure Security: Advanced Encryption Standard (AES) safeguards data against unauthorized access at all times.
  • Remote Control: CoreRescue OOB Module (Optional) makes monitoring and recovery much easier and more efficient through Cloud.



Equipped with advanced technologies support:

  • LDPC (Low Density Parity Check) ECC Engine: Enhance SSD endurance and data reliability.
  • Global Wear-leveling Technology: Ensure having lower erase counts to extend SSD lifespan.
  • Flash Bad-block Management: Manage cell blocks that fail over time.
  • S.M.A.R.T.: Provide proactive SSD health management.
  • End-to-End Data Protection: Protect sensitive data with comprehensive security.
  • Sidefill Technology: Ensures consistent operation even in high-vibration and extreme environmental conditions.
  • Others: ATA Secure Erase, TRIM, Page Mapping, Hyper Cache Technology, Over-provisioning, Device Sleep, SATA Power Management, DataRAID and DataDefender.



With its exceptional performance, proven reliability, and enhanced data protection, SV24C-M280 is an ideal storage or cache solution for a variety of markets, including industrial, imaging, computing, and enterprise.

規格表
  • Model
    SV24C-M280 CoreSnapshot 3 Cloud Edition
  • Interface
    SATA 3.2 (6Gb/s)
  • Connector
    M.2 B & M Key
  • Form Factor
    M.2 2280-D5-B-M
  • NAND Flash Type
    3D TLC
  • Capacity
    120GB~960GB
  • External DRAM
    No
  • Sequential Read Performance (MB/sec)
    Up to 565
  • Sequential Write Performance (MB/sec)
    Up to 395
  • ECC Engine
    Low-Density Parity-Check (LDPC) Code
  • IOPS (4K Random Write)
    68K
  • Standard Operating Temperature (°C )
    0 ~ 70
  • Extended Operating Temperature(°C )
    -40 ~ 85
  • Storage Temperature(°C )
    -55 ~ 100
  • Thermal Sensor
    Yes
  • Shock
    Operation: 50G/11ms
    (Compliant with MIL-STD-202G)
    Non-operation: 1500G/0.5ms
    (Compliant with MIL-STD-883K)
  • Vibration
    Operation: 7.69 GRMS, 20~2000 Hz/random
    (Compliant with MIL-STD-810G)
    Non-operation: 4.02 GRMS, 15~2000 Hz/random
    (Compliant with MIL-STD-810G)
  • Operating Voltage
    3.3 V ± 5%
  • Power Consumption
    Active Mode: 635 mA / Idle Mode: 85 mA
  • Dimension (L x W x H )
    Double Side: 22.00 mm x 80.00 mm x 4.53 mm
  • MTBF (hours)
    >3,000,000
