2.5吋固態硬碟

SV24C-25 CoreSnapshot 3 Cloud Edition

2.5吋固態硬碟

SV24C-25 CoreSnapshot 3 Cloud Edition

  • Low-Density Parity-Check (LDPC) Code
  • Global Wear-leveling
  • Flash Bad-block Management
  • S.M.A.R.T.
  • End-to-End Data Protection
  • CoreSnapshot 3
  • ATA Secure Erase
  • TRIM
  • Flash Translation Layer: Page Mapping
  • Hyper Cache Technology
  • Over-provisioning
  • Device Sleep
  • SATA Power Management
  • DataRAID
  • SMART Read Refresh
  • DataDefender

SV24C-25 Ensures Outstanding Performance and Security
with Advanced Instant Recovery and Security Technologies



Apacer SV24C-25 with CoreSnapshot 3 technology is designed with a SATA 6 Gb/s interface, fully complying with the latest SATA Revision 3.2 specifications, delivering outstanding read and write speeds. Its random performance is further enhanced by the integration of DRAM in the internal controller, making it ideal for heavy-load industrial or server operations.



With Apacer’s storage solutions, you’ll experience:

  • 3D NAND Technology: Offer superior power efficiency than 2D NAND.
  • Instant Recovery: CoreSnapshot Technology minimizes downtime and maximums output.
  • Ensure Security: Advanced Encryption Standard (AES) safeguards data against unauthorized access at all times.
  • Remote Control: CoreRescue OOB (Optional) makes monitoring and recovery much easier and more efficient through Cloud.



Equipped with advanced technologies support:

  • LDPC (Low Density Parity Check) ECC Engine: Enhance SSD endurance and data reliability.
  • Global Wear-leveling Technology: Ensure having lower erase counts to extend SSD lifespan.
  • Flash Bad-block Management: Manage cell blocks that fail over time.
  • S.M.A.R.T.: Provide proactive SSD health management.
  • End-to-End Data Protection: Protect sensitive data with comprehensive security.
  • Others: ATA Secure Erase, TRIM, Page Mapping, Hyper Cache Technology, Over-provisioning, Device Sleep, SATA Power Management, DataRAID, and DataDefender.



With its exceptional performance, proven reliability, and enhanced data protection, SV24C-25 is an ideal storage or cache solution for a variety of markets, including industrial, imaging, computing, and enterprise.

規格表
  • Model
    SV24C-25 CoreSnapshot 3 Cloud Edition
  • Interface
    SATA 3.2 (6Gb/s)
  • Connector
    (7+15) pin
  • Form Factor
    2.5"
  • NAND Flash Type
    3D TLC
  • Capacity
    120GB~960GB
  • External DRAM
    No
  • Sequential Read Performance (MB/sec)
    Up to 560
  • Sequential Write Performance (MB/sec)
    Up to 395
  • ECC Engine
    Low-Density Parity-Check (LDPC) Code
  • IOPS (4K Random Write)
    72K
  • Standard Operating Temperature (°C )
    0 ~ 70
  • Extended Operating Temperature(°C )
    -40 ~ 85
  • Storage Temperature(°C )
    -55 ~ 100
  • Thermal Sensor
    Yes
  • Shock
    Operation: 50G/11ms
    (Compliant with MIL-STD-202G)
    Non-operation: 1500G/0.5ms
    (Compliant with MIL-STD-883K)
  • Vibration
    Operation: 7.69 GRMS, 20~2000 Hz/random
    (Compliant with MIL-STD-810G)
    Non-operation: 4.02 GRMS, 15~2000 Hz/random
    (Compliant with MIL-STD-810G)
  • Operating Voltage
    5.0 V ± 5%
  • Power Consumption
    Active Mode: 500 mA / Idle Mode: 100 mA
  • Dimension (L x W x H )
    7mm: 100.00 x 69.85 x 6.90 mm
  • MTBF (hours)
    >3,000,000
