M.2

SV240-M280 CoreSnapshot 3 Client Edition

M.2

SV240-M280 CoreSnapshot 3 Client Edition

  • Low-Density Parity-Check (LDPC) Code
  • Global Wear-leveling
  • Flash Bad-block Management
  • S.M.A.R.T.
  • End-to-End Data Protection
  • Sidefill Technology
  • CoreSnapshot 3
  • ATA Secure Erase
  • TRIM
  • Flash Translation Layer: Page Mapping
  • Hyper Cache Technology
  • Over-provisioning
  • Device Sleep
  • SATA Power Management
  • DataRAID
  • SMART Read Refresh
  • DataDefender

SV240-M280 Ensures Outstanding Performance and Security
with Advanced Instant Recovery and Security Technologies



Apacer SV240-M280 with CoreSnapshot 3 technology is designed with a SATA 6 Gb/s interface, fully complying with the latest SATA Revision 3.2 interface specifications, delivering exceptional read and write speeds. These features make it the perfect choice for demanding industrial or server operations with heavy workloads.



With Apacer’s storage solutions, you’ll experience:

  • 3D NAND Technology: Offer superior power efficiency than 2D NAND.
  • Instant Recovery: CoreSnapshot Technology minimizes downtime and maximums output.
  • Ensure Security: Advanced Encryption Standard (AES) safeguards data against unauthorized access at all times.



Equipped with advanced technologies support:

  • LDPC (Low Density Parity Check) ECC Engine: Enhance SSD endurance and data reliability.
  • Global Wear-leveling Technology: Ensure having lower erase counts to extend SSD lifespan.
  • Flash Bad-block Management: Manage cell blocks that fail over time.
  • S.M.A.R.T.: Provide proactive SSD health management.
  • End-to-End Data Protection: Protect sensitive data with comprehensive security.
  • Sidefill Technology: Ensures consistent operation even in high-vibration and extreme environmental conditions.
  • Others: ATA Secure Erase, TRIM, Page Mapping, Hyper Cache Technology, Over-provisioning, Device Sleep, SATA Power Management, DataRAID and DataDefender.

With its exceptional performance, proven reliability, and enhanced data protection, SV240-M280 is an ideal storage or cache solution for a variety of markets, including industrial, imaging, computing, and enterprise.

规格表
  • 型号
    SV240-M280 CoreSnapshot 3 Client Edition
  • 介面
    SATA 3.2 (6Gb/s)
  • 接口
    M.2 B & M Key
  • 板型
    M.2 2280-D5-B-M
  • NAND 颗粒
    3D TLC
  • 容量
    120GB~960GB
  • 外置DRAM
    No
  • 读取速度(MB/sec)
    Up to 565
  • 写入速度(MB/sec)
    Up to 395
  • ECC纠错功能
    Low-Density Parity-Check (LDPC) Code
  • IOPS (4K 随机写入)
    68K
  • 标准作业温度(°C)
    0 ~ 70
  • 最高作业温度(°C)
    -40 ~ 85
  • 放置温度(°C)
    -55 ~ 100
  • 温度感测功能
    Yes
  • 冲击耐力
    Operation: 50G/11ms
    (Compliant with MIL-STD-202G)
    Non-operation: 1500G/0.5ms
    (Compliant with MIL-STD-883K)
  • 震动耐力
    Operation: 7.69 GRMS, 20~2000 Hz/random
    (Compliant with MIL-STD-810G)
    Non-operation: 4.02 GRMS, 15~2000 Hz/random
    (Compliant with MIL-STD-810G)
  • 电压
    3.3 V ± 5%
  • 用电量
    Active Mode: 635 mA / Idle Mode: 85 mA
  • 尺寸 (L x W x H )
    Double Side: 22.00 mm x 80.00 mm x 4.53 mm
  • MTBF (小时)
    >3,000,000
