SV250-M280 CoreRescue ASR
M.2
SV250-M280 CoreRescue ASR
- CoreRescue ASR (Auto Self Recovery)
- Low-Density Parity-Check (LDPC) Code
- Global Wear Leveling
- Flash bad-block management
- Flash Translation Layer: Page Mapping
- S.M.A.R.T.
- DataDefender™
- Device Sleep
- ATA Secure Erase
- TRIM
- Hyper Cache Technology
- Over-provisioning
- SMART Read Refresh™
製品仕様
-
製品名SV250-M280 CoreRescue ASR
-
接続インターフェースSATA 3.2 (6Gb/s)
-
コネクタ75-pin SATA-based M.2 module pinout
-
形状Single-sided: M.2 2280-B-M S3
Double-sided: M.2 2280-B-M D5 -
NANDフラッシュタイプ3D TLC
-
容量Single-sided: 60, 120, 240 GB
Double-sided: 480 GB -
外付けDRAMNo
-
シーケンシャルリード(MB/s)Up to 560
-
シーケンシャルライト(MB/s)Up to 505
-
ECC訂正能力Low-Density Parity-Check (LDPC) Code
-
IOPS (4Kランダム書き込み)74K
-
標準動作温度(°C )0 ~ + 70
-
拡張動作温度(°C )-40°C to 85°C
-
保存温度(°C)-55°C to 100°C
-
サーマルセンサーYes
-
耐衝撃性Operation: Acceleration, 50(G)/11(ms)/half sine
(compliant with MIL-STD-202G)
Acceleration, 1500(G)/0.5(ms)/half sine
(compliant with MIL-STD-883K) -
耐振動性Operation:7.69(Grms), 20~2000(Hz)/random
(compliant with MIL-STD-810G)
Non-operation:4.02(Grms), 15~2000(Hz)/random
(compliant with MIL-STD-810G) -
動作電圧3.3 V ± 5%
-
消費電力Active mode: 400 mA / Idle mode:65 mA
-
寸法 (長さ×幅×高さ)Single-sided: 22.00 x 80.00 x 2.38(max.)(unit: mm)
Double-sided: 22.00 x 80.00 x 3.88(max.)(unit: mm) -
MTBF (時間)>3,000,000
