SM170-18
SM170-18
- Low-Density Parity-Check (LDPC) Code
- Global Wear-leveling
- Flash Bad Block Management
- Flash Translation Layer: Page Mapping
- S.M.A.R.T.
- TRIM
- ATA Secure Erase
- Power Failure Management
- SSDWidget
- Hyper Cache Technology
- SMART Read Refresh™
Outstanding Performance and Reliability – Explore More on SM170-18
Struggling with poor performance and reliability of your storage devices? Apacer’s SM170-18 is designed to meet the growing demands of today’s server and networking application. Built with full compliance to SATA 6 Gb/s interface, delivering exceptional read and write speeds that keep your systems running at better efficiency. These features make it the perfect choice for demanding industrial or server operations with heavy workloads.
With Apacer’s storage solutions, you’ll experience:
- Superior Power Efficiency: 3D NAND Technology offers better performance than 2D NAND.
- Outstanding Data Transmission: on-the-module ECC provides extraordinary data transfer performance.
- Ensure Reliability: S.M.A.R.T.: Provide proactive SSD health management.
Equipped with advanced technologies support:
- LDPC (Low Density Parity Check) ECC Engine: Enhance SSD endurance and data reliability.
- Global Wear-leveling Technology: Ensure having lower erase counts to extend SSD lifespan.
- Flash Bad-block Management: Manage cell blocks that fail over time.
- End-to-End Data Protection: Protect sensitive data with comprehensive security.
- Others: ATA Secure Erase, TRIM, Page Mapping, Hyper Cache Technology, and Smart Read Refresh.
With its exceptional performance and reliability, SM170-18 is an ideal storage or cache solution for a variety of application, including server and networking.
-
製品名SM170-18
-
接続インターフェースSATA III
-
コネクタ(7+15) pin male
-
形状1.8"
-
NANDフラッシュタイプ2D MLC
-
容量256GB~512GB
-
外付けDRAMNo
-
シーケンシャルリード(MB/s)Up to 550
-
シーケンシャルライト(MB/s)Up to 480
-
ECC訂正能力Low-Density Parity-Check (LDPC) Code
-
IOPS (4Kランダム書き込み)70K
-
拡張動作温度(°C )-40 ~ 85
-
保存温度(°C)-55 ~ 100
-
サーマルセンサーYes
-
耐衝撃性Operation: Acceleration, 50(G)/11(ms)/half sine
(Compliant with MIL-STD-202G)
Non-operation: Acceleration,1,500(G)/0.5(ms)/half sine
(Compliant with MIL-STD-883K) -
耐振動性Operation:7.69 Grms, 20~2000 Hz/random
(Compliant with MIL-STD-810G)
Non-operation:4.02 Grms, 15~2000 Hz/random
(Compliant with MIL-STD-810G) -
動作電圧3.3V ± 5% / 5V ± 5%
-
消費電力3.3V: Active mode (Max.): 800 mA / Idle mode: 100 mA
5V: Active mode (Max.): 510 mA / Idle mode: 70 mA -
寸法 (長さ×幅×高さ)78.50 x 54.00 x 5.00, unit: mm
-
MTBF (時間)>2,000,000
