2.5"

SH240-25

2.5"

SH240-25

  • Low-Density Parity-Check (LDPC) Code
  • Flash Bad Block Management
  • Global Wear-leveling
  • DataDefender™
  • ATA Secure Erase
  • TRIM
  • Flash Translation Layer: Page Mapping
  • S.M.A.R.T.
  • Device Sleep
  • SATA Power Management
  • SLC-liteX (P/E cycles: 100K)
  • DataRAID™
  • SMART Read Refresh™

Apacer’s SH240-25 is a well-balanced solid-state drive (SSD) featuring a standard form factor and exceptional performance. Designed with a SATA 6 Gb/s interface, SH240-25 fully complies with the latest SATA Revision 3.2 specifications and delivers outstanding read/write speeds. Its random performance is further enhanced by the integration of DRAM in the internal controller, making it ideal for heavy-load industrial or server operations.


Utilizing 3D NAND technology for higher capacities up to 640GB and providing greater power efficiency than 2D NAND, SH240-25 is built with a powerful SATA controller that supports on-the-module ECC and an efficient wear leveling scheme. It also features an LDPC (Low Density Parity Check) ECC engine and SLC-liteX technology with P/E cycles support of up to 100,000 times, extending SSD endurance and enhancing data reliability. Additionally, SH240-25 includes a built-in thermal sensor to monitor the SSD's temperature via S.M.A.R.T commands, preventing overheating. For highly-intensive applications, End-to-End Data Protection ensures data integrity is maintained at multiple points along the data transfer path, enabling reliable data delivery.


In terms of security, SH240-25 offers robust data protection with Advanced Encryption Standard to safeguard against unauthorized access. It also includes numerous advanced features such as flash block management, DataDefender, ATA secure erase, TRIM, page mapping, device sleep, power-saving modes, DataRAID, and SMART Read Refresh.


With exceptional performance, proven reliability, and enhanced data protection, SH240-25 is the ideal storage.

製品仕様
  • 製品名
    SH240-25
  • 接続インターフェース
    SATA 3.2 (6Gb/s)
  • コネクタ
    (7+15) pin male
  • 形状
    2.5"
  • NANDフラッシュタイプ
    3D TLC
  • 容量
    40GB-640GB
  • 外付けDRAM
    No
  • シーケンシャルリード(MB/s)
    Up to 560
  • シーケンシャルライト(MB/s)
    Up to 495
  • ECC訂正能力
    Low-Density Parity-Check (LDPC) Code
  • IOPS (4Kランダム書き込み)
    81K
  • 標準動作温度(°C )
    0 ~ 70
  • 拡張動作温度(°C )
    -40 ~ 85
  • 保存温度(°C)
    -55 ~ 100
  • サーマルセンサー
    Yes
  • 耐衝撃性
    Operating:Acceleration, 50(G)/11(ms)/half sine
    (Compliant with MIL-STD-202G)
    Non-operating:Acceleration, 1500(G)/0.5(ms)/half sine
    (Compliant with MIL-STD-883K)
  • 動作電圧
    5V ± 5%
  • 消費電力
    Active Mode: 465 mA / Idle Mode: 100 mA
  • 寸法 (長さ×幅×高さ)
    100.00 x 69.85 x 6.90, unit: mm
  • MTBF (時間)
    >3,000,000
